Hydraulic Drum Angle
The hydraulic angle adjustment allows the operator to hydraulically angle the entire machine on the go. Drum Angle can be adjusted from 10° to 30° to achieve the optimum working angle to suit various windrowing conditions.
Hard Surfaced Reversible/Replaceable Teeth
These hard surfaced teeth are manufactured using a special grade of steel to avoid breaking and bending. These teeth also provide maximum wear as they can be rotated to use both sides. When teeth do have to be replaced, this can be done without changing the entire drum.
Optional Hydraulic Drum
The optional hyraulic powered drum allows for tight turning, quick hitching and reduced drive maintenance. The heart of Parker’s TK-series powertrain, the torque link, is an extra-heavy-duty part that includes patented
60:40 spline geometry. Rugged construction throughout allows the transmission of over 23,000 lb-in of torque. The entire powertrain is continually washed in cool, high flow fluid to assure long life. Roller vanes and sealed
commutator maintain high efficiency and provide smooth low speed performance.
For years rural municipalities have saved thousands of dollars, reclaiming up to 75% of their lost gravel with a Degelman Rock Rake. A simple sprocket change in the transfer case will speed the output drum to the optimum speed for breaking lumps, pulling up and sifting shoulder side gravel off of rural roads.
Extreme Duty Chain Oil Bath
Built for extreme duty, this easy to service chain housing unit provides a continuous oil bath for constant lubrication. It also incorporates our improved chain tightening system for quick and simple adjustment.
Hydraulic Folding System
The hydraulic folding system comes standard on every machine, and provides for an easy narrow transport width of eight feet and a working position of 14 feet.
The rock rake drive train is a whole-drive system consisting of heavy duty drivelines, gear box, #100 roller chain, and slip clutch. The entire rock rake is driven either hydraulically or by 540/1000 PTO.
The floating drum absorbs the shock of buried obstructions taking the stress off the machine.
|Hitch Weight||475 lbs|
|Horsepower (min)||75 hp|
|Drum Angle||10° - 30°|
|Frame||6" x 6" x 1/4"|
|Drive - PTO||1000/540/540 Municipal|
|Drive - Hydraulic (min)||17 gpm @ 2,700 psi|
|Drive - Hydraulic (ideal)||20-30 gpm @ 3,000 psi|
|Teeth||Hard Surfaced (Reversible/Replaceable)|
|Angling Cylinder||3" x 8" x 1-1/4" Rod|
|Lifting Cylinder||3" x 8" x 1-1/4" Rod|
|Tires||9.5L x 15 Highway|
