FAST Sprayers

Pull Type Sprayers

  • 9500TF

    9500TF

    A high capacity model with 1800 or 2400 gallon Fast "Stealth" tanks and boom sizes ranging from 60-100'

    Read More →
  • 9500T

    9500T

    Fast's largest pull type sprayer with 120' and 132' truss style booms and Fast "Stealth" tank capacities of 1800 or 2400 gallons

    Read More →
  • 9600N/TF

    9600N/TF

    A sprayer with a very compact design with 60-100' booms and 1050 or 1350 gallon Fast "Stealth" tank capacities

    Read More →
  • Big Wheel

    Big Wheel

    The smallest sprayer model Fast offers with a 45-60' boom and 500-750 gallon tank capacities

    Read More →

Model9600N/TF (60'-100')9500TF (60'-100')9500T (120'-132')953P (60'-100')Big Wheel (45' or 60')
Transport Height 10'7" (60') 11'10" (90') 10'8" (60') or 11'11" (100') 13'3" N/A (Tractor Dependent) 8'4" (500 BW)
Transport Width 10'1" - 60', 66', 88', 90' (N) 12'3" - 80', 100' (TF) 12'3" (100') 12'4" 12'3" 8'1" (500 BW)
Transport Length 18' 5" 21'6" 23'10" 12'9" 17'6"(500 BW)
Transport Weight Empty 7620 (9613N 90') 8300 (9518 90') 11860 (9518T 120') 5,620 (90') 3240 (500 BW)
Field Weight Tanks Full 19780 (9613N 90') 24090 (9518 90') 27200 (9518T 120') 9,620 (500 Gal 90') 11,880 (750 Gal 90') 8320 (500 BW)
Tank Size Gallons 1050 or 1350 1800 or 2400 1800 or 2400 500 or 750 500 or 750
Boom Sizes 60', 66', 80', 88', 90', 100' 60', 66', 80', 88', 90', 100' 120' or 132' 60', 66', 80', 88', 90', 100' 45' (BW500) or 60' (BW750)
Tank Rinse System 100 Gallon Rinse Tank 100 Gallon Rinse Tank 100 Gallon Rinse Tank 50 Gallon Rinse Tank 50 Gallon Rinse Tank
Standard Pump Ace 150-206F (60',66') or Ace 205-304F (80'-100') Ace 205-304F Ace 205-304F Ace 150-206F (60',66') or Ace 205-304F (80'-100') Ace 150-206F or Ace 540 PTO
Tires 13.6x38" or 320/90R46 380/90R46 or 480/80R50 380/90R46 or 480/80R50 N/A 12.4x24" or 11.2x38"
Dual Wheel Capability Yes: 62"-120", 80"-120", 88"-132" Yes: 62"-120", 80"-120", 88"-132" Yes: 62"-120", 80"-120", 88"-132" N/A No
Quick Fill 2" 3" 3" 2" 2"
Hitch-pin-to-axle length 152" 175" 175" N/A 144" (500 BW)






Three Point Sprayers

953P

Boom Flexibility/Excellent Visibility

The 80' boom is designed to fold to spray at 40' and the 90' booms will fold to spray at 60', allowing you to stay on your planter tracks on headlands and field borders. This helps minimize traffic patterns in your fields.

FAST's Tri-Fold boom design provides a very compact transport length which gives the operator excellent visibility from the cab when traveling between fields.

Excellent Versatility/Reduced Costs per Acre

The FAST 3-point booms give you the ability to increase the productivity and profitability of your operation. These booms excel when spraying field borders and maneuvering in tighter fields to provide decreased crop damage. Pair these booms with FAST's Track Tanks to achieve an additional 1000 gallons of capacity and get much better flotation as well as a sprayer at a fraction of the cost of any self-propelled option to help reduce your costs per acre and keep more revenue in your pocket.

Minimized Crop Damage

The 953P allows you to utilize a tractor that you have already purchased for your operation and minimize your footprint out in the field. This is extremely beneficial when spraying field borders and in smaller or more hilly fields. Own this sprayer at a fraction of the cost of any self-propelled option to help reduce your costs per acre and keep more revenue in your pocket.

Single Main Tank

Other designs utilize two tanks rather than one. A single tank design provides for better/even cleanout of the tank and the ability to keep your pump primed on hillsides.


Easy to Access and Understand Plumbing

Similar to all FAST sprayer designs, the 953P has all of its main plumbing controls on one side of the sprayer, is easy to access, and is straightforward and easy to understand.






963PTF

Excellent Versatility/Reduced Costs per Acre

The FAST 3-point booms give you the ability to increase the productivity and profitability of your operation. These booms excel when spraying field borders and maneuvering in tighter fields to provide decreased crop damage. Pair these booms with FAST's Track Tanks to achieve up to 1000 gallons of capacity and get much better flotation as well as a sprayer at a fraction of the cost of any self-propelled option to help reduce your costs per acre and keep more revenue in your pocket.

Multiple Boom Sizes - Tri-Fold Boom

We realize every farmer is different and runs a different operation so that is why with the 963PTF series we give the operator the ability to choose between 6 different boom sizes of 60', 66', 80', 88', 90' and 100', to best match up with their planting width. The 80' and 100' booms have the ability to fold and spray at 40' and the 90' boom is able to fold and spray at 60' to allow you to stay on your planter tracks on headlands and field borders to minimize traffic patterns in the field.

Hydraulic Accumulated Center Pivot Center Section

We know that killing weeds is a top priority, so we incorporate a center-pivot boom into all of our sprayers. Because the boom is de-coupled from the tractor, it stays level with the ground, providing a superior boom ride. This means an unbeatable tip-to-target spray pattern, and ultimately, superior weed kill. This also allows the operator to spray at higher speeds, so they are able to cover more acres per hour. Due to the center section being isolated from the tractor this allows for a wide arrange of spray heights. So spraying late in the season will not be a problem due to the adjustable range of the 963PTF center section.

Parallel Link System

All of Fast's 3 point mounted sprayers use the same parallel link system as our trailer sprayers. This gives the operator maximum boom height adjustability for all stages of crop growth.

Powder-Coat Paint


When you make an investment in equipment, you want it to last, which is why Fast's equipment is all finished with baked-on powder coat paint. Powder coat paint gives equipment great resistance to harsh chemicals, which leads to a longer life and better resale value for you.






973PT

ISO Hydraulic Yaw System

FAST includes standard on the 973PT series a hydraulic yaw cushioning system that is controlled through and ISO compatible display (2630/Pro 700,ect.). This system has a sensor that is mounted to the center section and senses at all times what the position of the wing is. If the wing starts moving forward and backward due to a sudden start, stop, turn, ect. the sensor will pick that up and apply hydraulic cushioning through the hydraulic fold cylinder to bring the boom to a controlled/cushioned stop and also to bring the boom back to its "home" position. This system helps significantly when there is sudden tractor movements caused by auto-steer or sudden stops, when turning on ends, and also help prevent any "boom walk" that may be experienced with other booms. This is unique system that is offered on FAST booms. (Please see the video above explaining how this system works)

Hydraulic Accumulated Center Pivot Center Section

We know that killing weeds is a top priority, so we incorporate a center-pivot boom into all of our sprayers. Because the boom is de-coupled from the tractor, it stays level with the ground, providing a superior boom ride. This means an unbeatable tip-to-target spray pattern, and ultimately, superior weed kill. This also allows the operator to spray at higher speeds, so they are able to cover more acres per hour. Due to the center section being isolated from the tractor this allows for a wide arrange of spray heights. So spraying late in the season will not be a problem due to the adjustable range of the 973PT center section.

Parallel Link System

All of Fast's 3 point mounted sprayers use the same parallel link system as our trailer sprayers. This gives the operator maximum boom height adjustability for all stages of crop growth.

Powder-Coat Paint


When you make an investment in equipment, you want it to last, which is why Fast's equipment is all finished with baked-on powder coat paint. Powder coat paint gives equipment great resistance to harsh chemicals, which leads to a longer life and better resale value for you.

Excellent Versatility/Reduced Costs per Acre

The FAST 3-point booms give you the ability to increase the productivity and profitability of your operation. These booms excel when spraying field borders and maneuvering in tighter fields to provide decreased crop damage. Pair these booms with FAST's Track Tanks to achieve up to 1000 gallons of capacity and get much better flotation as well as a sprayer at a fraction of the cost of any self-propelled option to help reduce your costs per acre and keep more revenue in your pocket.






Front Mount Sprayers

94FM

Hydraulic Accumulated Center Pivot Center Section


We know that killing weeds is a top priority, so we incorporate a center-pivot boom into all of our sprayers. Because the boom is de-coupled from the tractor, it stays level with the ground, providing a superior boom ride. This means an unbeatable tip-to-target spray pattern, and ultimately, superior weed kill. This also allows the operator to spray at higher speeds, so they are able to cover more acres per hour. Due to the center section being isolated from the tractor this allows for a wide arrange of spray heights of anywhere between 20" to 72". So spraying late in the season will not be a problem due to the adjustable range of the 94FM center section.

Operator Friendly

The Fast 94FM sprayer was built to be operator friendly. The outstanding visibility of the entire boom can reduce crop damage for the operator, keeping more money in your pocket.

Stainless Steel Wet Boom Plumbing

All Fast Sprayers are equipped with stainless steel wet boom plumbing. This allows for excellent chemical residue cleanout which results in less chance of chemical carryover. This will allow the operator to spray at higher flow rates.

Powder-Coat Paint


When you make an investment in equipment, you want it to last, which is why Fast's equipment is all finished with baked-on powder coat paint. Powder coat paint gives equipment great resistance to harsh chemicals, which leads to a longer life and better resale value for you.
