Loftness Standard-Duty 35-120 HP
Tractor Rear-Mount Standard-Duty 35-120 HP
Overview:
With the S Series, Loftness offers the most capable line of heavy-duty snow blowers available. Loftness has designed five models that get the most from the power of your small to mid-sized tractor. For landowners and facilities managers, the S Series delivers the efficiency of using your equipment year-round, as well a... + Read More
Get A Quote
Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.
Send To A Friend
Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.
Features
Spout
•Telescoping hand crank rotator: 721S & 841S (hydraulic or electric optional)
•Hydraulic motor, gear drive rotator: 842S, 961S & 962S
•11-inch diameter: 721S & 841S
•14-inch diameter: 842S, 961S & 962S
•Manually adjustable deflector (hydraulic or electric optional)
Discharge Fan
•27-inch diameter housing, 3 blades, 8-inch-deep fan housing: 721S & 841S
•30-inch diameter housing, 4 blade, 11-inch deep fan housing: 842S, 961S & 962S
•540 RPM only
Augers
•Heavy-duty open-spoke design
•1 (16 inch): 721S & 841S
•1 (24 inch): 961S
•2 (16 inch): 842S & 962S
Cutting Capacity
•32-inch cutting height and 72- or 84-inch widths: 721S & 841S
•40-inch cutting height and 96-inch widths: 961S
•48-inch cutting height and 84- or 96-inch widths: 842S & 962S
Gearbox
•120 HP oil-bath gearbox
Mount
•Standard three-point hitch ◦Category II free link: 721S & 841S* ◾*Category 1 (optional)
◦Category II or III (Quick-hitch only): 842S, 961S & 962S
Shear Bolts
•PTO shaft
•Auger drive sprocket
•Auger driven sprocket
The Nuts and Bolts
Drive and Power Requirements
•540 RPM PTO only
•35 to 120 HP
Components
•No. 60 roller chain: 721S & 841S
•No. 60 HD: 842S, 961S & 962S
•1-3/8-inch cross shaft bearings
•1-1/2-inch auger bearings
•Replaceable hardened steel, bolt-on cutting edge
•Adjustable skid shoes
Construction
•High-quality craftsmanship
•Laser-cut components
•12-gauge steel body
•1/4-inch end plates
•3/8-inch auger flighting
Specifications
| Model | 721S | 841S | 961S | 842S | 962S |
| Series | S-small | S-small | S-large | S-large | S-large |
| Width | 72 | 84 | 96 | 84 | 96 |
| Height | 32 | 32 | 40 | 48 | 48 |
| Input Power | 35-80 hp | 40-120 hp | 80-120 hp | 60-120 hp | 90-120 hp |
| Weight | 832 | 877 | 1500 | 1540 | 1620 |
| Fan Diameter | 27 in. | 27 in. | 30 in. | 30 in. | 30 in. |
| Fan Housing Depth | 8 | 8 | 11 | 11 | 11 |
| Diameter of Auger | 16 in. | 16 in. | 24 in. | 16 in. | 16 in. |
| Number of Augers | 1 | 1 | 1 | 2 | 2 |
| Gearbox | 120 hp | 120 hp | 120 hp | 120 hp | 120 hp |
| Chain | #60 | #60 | #60 HD | #60 HD | #60 HD |
| Bearings | 1-3/8 in | 1-3/8 in | 1-3/8 in HD | 1-3/8 in HD | 1-3/8 in HD |
| Mount | Cat. 1 or 2 | Cat. 1 or 2 | Cat. 2 or 3* | Cat. 2 or 3* | Cat. 2 or 3* |
| Spout Diameter | 11 in. | 11 in. | 14 in. | 14 in. | 14 in. |
*QUICK-HITCH REQUIRED
