| ENGINE |
| Engine Make |
Kawasaki FS541V |
| Rating / Displacement |
15** |
| PTO |
Electric |
| Cylinders |
2 |
| Starting |
Manual |
| Fuel Tank Capacity (Total) |
5 |
| MOWER |
| Cutting Width (in.) |
48" |
| Cutting Height (in.) |
1.5" - 4.5" |
| Spindles |
Cast-aluminum, greaseable |
| Deck Construction |
10-gauge, fabricated, double top deck, double reinforced side skirts, overlap welded corners |
| DRIVE TRAIN |
| Transmission |
Dual, commercial Hydro-Gear® ZT-3100® transaxles with 7" mounted cooling fans |
| Drive Axles |
1" Tapered |
| Drive Tires |
20 x 7-10 |
| Caster Tires (in.) |
9 x 3.5-4 Flat-Free |
| GROUND SPEED |
| Speeds-Fwd. (mph) |
0-6.25 |
| Speeds-Rev. (mph) |
0-3 |
| DIMENSIONS |
| Overall Length |
75.5" |
| Overall Width (in.) Deflector Down/Deflector Up |
61" / 49.5" |
| Dry Weight |
694 |
| OPERATOR CONTROL & COMFORT SYSTEMS |
| Control/Safety Group |
Operator presence, centralized foot activated neutral pedals, neutral start safety circuit / Standard controls |
| Parking Brake/Safety Circuit |
Internal Transaxle |
