| ENGINE |
| Engine Brand |
Vanguard™ 810cc EFI |
| Rating / Displacement |
28 gross hp* / 810cc |
| PTO |
Electric |
| Cylinders |
2 |
| Starter |
Electric |
| Fuel Tank Capacity |
11 gal. |
| MOWER |
| Cutting Width (in.) |
61" |
| Cutting Height (in.) |
1.75"- 5.0" |
| Spindles |
Cast-iron Greaseable |
| Deck Construction |
iCD™ Cutting System with professional lawn striper |
| SUSPENSION |
| Suspension |
Adjustable rear coil-over-shocks and front independent adjustable coil-over-shocks |
| DRIVE TRAIN |
| Transmission |
Dual, commercial Hydro-Gear® ZT-4400™ transaxles with 8.3" cooling fans |
| Drive Axles |
1.375" |
| Caster Tires (in.) |
13 x 6.5-6 |
| Drive Tires (in.) |
24 x 12-12 |
| GROUND SPEED |
| Speeds-fwd. (mph) |
0-10 |
| Speeds-rev. (mph) |
0-6 |
| DIMENSIONS |
| Overall Length |
82.5" |
| Overall Width (in.) deflector down / deflector up (model) |
78" / 61.5" |
| Dry Weight (lbs.) |
1295 |
| OPERATOR CONTROL & COMFORT SYSTEMS |
| Seat Package |
Premium mid-back adjustable seat |
| Certified Roll-over Protection System |
Standard, 180° foldable |
| Instrumentation |
Fuel level gauge in each tank, Hour meter |
| Controls / Safety Group |
Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit |
| Parking Brake / Safety Circuit |
Internal Transaxles |
